frame specs
Reach 509mm
Effective top tube 680mm
Seat tube (ctr to top) 565mm
Head tube length 250mm
Bottom bracket height 270mm
Chainstay length 417mm
Wheel base 1190mm
Head tube angle 70deg
Seat tube angle 76deg
Bottom Bracket Threaded Euro 73mm
Rear axle/Spacing 142 X 12mm
Prescribed stem length 50 - 70mm
Components
Headset Chris King Inset 1 1/8” Burnt Orange
Fork Surly Disc Trucker
Wheels FSA Non Series Front hub 12 X 100mm
Rear hub 12 X 142
-Upgraded with matching Orange alloy nipples, hand tensioned
Tires WTB Vulpine 40 X 700c
Stem Whisky No. 7 Stem 50mm, 31.8 clamp
Handlebar Salsa Cowchipper 31.8mm X 48cm
Bar Tape Brooks Black leather
Brakes TRP
Rotors TRP Centerloc Front and Rear
Drivetrain Advent Microshift 9speed Rear derailleur
- 11-42 Cassette
- Race Face Aeffect CINCH crankset 175mm
-Easton 42T chainring
Saddle Sella San Marco Regal Black w/copper rivets
Seatpost Easton 27.2
Pedals Deity Orange
Tube set
Head Tube 44mm top and bottom
Front triangle/Main tubes Coumbus Zona
Chainstays Columbus Zona, S bend
Seatstays Columbus Zona 19mm
BB shell Threaded Euro 73mm
Drop-outs Tange Flat mount 12mm
Paint
Gloss Black with gold leaf letters. Orange pin striping on letters, frame and fork. White bronze head badge.
Features
-Wishbone seat stay lug w/integrated fender mounts
-Seat tube lug w/hand carved W
-Custom pin striping on all lugs
-Rack mounts
-4 WB cage mounts in main frame
-Tire clearance for 42mm tires
